● For vertical, horizontal CNC milling, precision machining for heavy cutting.
● There is the locking power of the ball-type semi-circular solid angle, and can eliminate the work piece tilted and the jaws floated.
● Vise is made of cast iron FCD60 with spherical graphite, and good anti tension, not deformed.
● The sliding surface of vise is heat treatment HRC45 degrees, can be maintained long-term wear and accuracy.
● The dust cover designed to prevent iron filings into the drive screw, causing the adverse action.
● Weight:60kg.
◆ Accuracy:
1.The parallelism of jaws: 100mm/0.02mm
2.The parallelism of the sliding surface: 100mm/0.01mm.
3.The Verticality of side sliding surface: 100mm/0.15mm.
4.The parallelism after clamping the work piece:100mm/0.03mm.
